IEC beschermingsklasse | Veiligheidsklasse I/II
|
Constante lichtopbrengst | Yes
|
Nominale levensduur (nom.) | 100000
h
|
Rimpel uitgangsstroom (max.) | 4
%
|
Maximaal rendement | 89
%
|
Uitgangsstroom (max.) | 1050
mA
|
Spanning circuitonderbreking (DC) (max.) | 60
V
|
Aanlooppiekstroom (max.) | 18,7
A
|
Uitgangsvermogen (max.) | 40
W
|
Duur aanloopstroom tot 50% van piek | 195
µs
|
Diagnostiek | True
|
Uitgangsvermogen (min.) | 1.5
W
|
Uitgangsstroom (min.) | 300
mA
|
Uitgangsspanning (max.) | 54
V
|
Uitgangsspanning (min.) | 20
V
|
Levensduur T-behuizing (max.) | 75
°C
|
T-behuizing maximaal (max.) | 85
°C
|
Dimbaar | 1-10 V
|
Dimbereik | 100-10
%
|
Productlengte | 123
mm
|
Behuizing | C123_LP_S1
|
Afmetingen behuizing | 123 x 79 x 31
|
Totale lengte | 123
mm
|
Totale breedte | 79
mm
|
Totale hoogte | 31
mm
|
Piekspanningsbeveiliging (gemeenschappelijk/differentiaal) | Piekspanningsbeschermingsniveau tot 6 kV met differentiaal-modus en 10 kV met normale modus
|
|||
IP-classificatie | IP 20
[ Ingress Protection 20] |
|||
Isolatieklasse | Class I and Class II
|
|||
Goedkeuringsmerktekens | CCC-certificaat
|
CE-markering
|
CB-certificaat
|
ENEC-certificaat
|
Instelopties uitgangsstroom | SimpleSet
|
Volledige productcode | 871869970390500
|
Productnaam voor bestelling | Xi LP 40W 0.3-1.0A S1 230V C123 sXt
|
EAN/UPC - Product | 8718699703905
|
Bestelcode | 70390500
|
Lokale code | 70390500
|
Numerator - Aantal per pak | 1
|
Numerator - Dozen per buitendoos | 20
|
SAP-materiaal | 929002103206
|
Net Weight (Piece) | 0,190
kg
|
